New multifunctional precision 400a digital clamp meter

Product Description

A digital clamp meter is a meter used to measure the magnitude of the current in a running electrical line, and it can measure the current without interruption. It is an electrical instrument specially designed to measure AC high current.

Multimeter digital AC DC Clamp Meter Chinese Factory

digital clamp meter2(1)
digital clamp meter4(1)
digital clamp meter5(1)
digital clamp meter8(1)
digital clamp meter2(1)
digital clamp meter4(1)
digital clamp meter5(1)
digital clamp meter8(1)

Product Details

This instrument is a new series of 3 1/2 digital clamp meters with automatic range conversion. It is a digital clamp meter with stable performance and high reliability driven by batteries. The meter has a unique small design. This clamp meter can be used to measure DC voltage, AC voltage, AC current, resistance, diode, capacitance, on-off test and other parameters. The whole machine is based on the double-integration A/D conversion of large-scale integrated circuits, and has the function of automatic range conversion.

3266TD digital clamp meters is a cost-effective product with the functions of temperature, frequency and capacitance measurement. It is praised by the market as a comprehensive instrument integrating pincer meter, multimeter, thermometer, frequency meter, capacitance pen and non-contact electric measuring pen. It is a special soldier in the instrument. According to the statistics of online sales platforms such as Taobao, the sales volume of this table ranks the top three, and has begun to export a large number to the international market.

It is widely used in families, schools, decoration, electricians, electronics, information, communication, petroleum, chemical industry, maintenance and other industries.

Product Parameter
Measuring Current Range
40A/400A
Measuring Voltage Range
400mV/4V/40V/400V/600V
Measuring Resistance Range
400Ω/40kΩ/400kΩ/4MΩ/40MΩ
Measuring Capacitance Range
5nF/50nF/500nF/5μF/50μF/200μF
Operating Temperature
-10~40℃
Dimensions
185 x 70 x 26mm
Product name
3266TD
Color
Black+Orange
Display
LCD
Battery type
2 x 1.5V AAA Battery(not included)
Automatic power off
yes
Diode Test
yes
DC voltage range
400mV/4V/40V/400V/600V
DC voltage accuracy
±2.5%+5
AC voltage range
400mV/4V/40V/400V/600V
AC voltage accuracy
±0.8%+5
Key Introduction
digital clamp meter1
digital clamp meter
Related Products
3266TA digital clamp meter*1
10A table pen* 1 pair
Instrument package*1
No. 7 dry battery*2
Temperature probe*1
H1f68682c145b421290481737ae3d2351w
Product Packaging
